Pallet Fork Hook

Pallet Fork Hooks – Fixed

Fixed position pallet fork hook for the safe movement of objects on the machines’ pallet forks.



Category:

Features

  • Fully tested and certified, supplied with test certificate
  • Complete with swivel hook and shackle
  • Positive fixings behind heel of fork
  • Fixed hook position @ 900mm load centre

Models

Model Truck lift capacity at 500 mm load centre Max. Fork Size Load Centre Centre of Gravity Weight
FMH900-2.0 2,000 kg 150 x 50 900 mm 651 mm 34 kgs
FMH900-3.0 3,000 kg 150 x 50 900 mm 651 mm 38 kgs
FMH900-5.0 5,000 kg 150 x 50 900 mm 651 mm 42 kgs
