Shear Grab
Shear GrabShear GrabShear Grab

Shear Grabs – Hardox Tines

The Albutt Shear Grab range is designed to give users a strong, reliable option for cutting clamp silage. Trusted all over the world, the Albutt name is synonymous with the quality Shear Grab product. High capacity rams, strategically placed offer unrivalled clamping power, with a Hardox blade leaving a smooth clamp face. The capacity of the hydraulic cylinders also means that minimum power is required to operate the grab

“At first we had reservations about moving onto a Hardox tine for our Shear Grab but we are so glad we did. Tine breakages are a thing of the past and we don’t have to worry about keeping them tight. They cut into the pit face well enough too”

S190HX user, Lamma Show 2017

Our Shear Grabs have been the recognised market leader for a number of years. Manufactured by ourselves in either our Tewkesbury or Evesham facilities, we are proud that our grabs are British built, supporting the British dairy industry.





Features

  • Hardox cutting blade
  • Double skinned front grab
  • Heavy duty thick wall box sections
  • Hardox base tines; 40mm wide
  • 50mm and 35mm pivot pins
  • 90mm bore rams on all models
  • Recommended to be used with Albutt’s bolt on bracket system – ask your dealer for details
  • 3 rams on S190 and above
  • Central cutting blade on S190 and above
  • Supplied with transport bolt to protect front blade when in delivery transit
  • Optional filled in back plate
  • Height 843mm / Depth 975mm / Jaw Opening 760mm

Featuring our ALS pin system – better lubrication properties than zinc plated pins

Video

Models

Model Width Rams Capacity Weight
S160HX 1600mm 2 0.85m3 525kgs
S190HX 1900mm 3 1.00m3 750kgs
S220HX 2200mm 3 1.15m3 800kgs

Want to know more? Request a call back from a member of our Sales Team
